Geekvape Aegis Legend 5 200W Mod Kit: Features, Specifications, and Setup Guide
The Geekvape Aegis Legend 5 is a 200W dual-battery vape mod kit built for durability and precise control. Pairing a rugged, weather-resistant chassis with a fast chip and a leak-resistant sub-ohm tank, it aims to serve both newer vapers and those who want detailed control over their setup. This guide walks through what the kit includes, its verified specifications, and practical tips for getting started.
What’s in the Box
The kit ships with the following components:
- 1x Aegis Legend 5 mod (batteries not included)
- 1x Z Sub-Ohm Tank 2021 (5.5ml)
- 2x Geekvape Z Series coils
- Pre-installed: Z0.15 XM — 0.15Ω, rated 70–85W
- Spare: Z0.4 XM — 0.4Ω, rated 50–60W
- 1x spare glass tube (5.5ml / 2ml TPD version)
- 1x spare parts pack
- 1x USB Type-C cable
Note that two 18650 batteries are required to operate the device and are not supplied in the box.
Power and Performance
At the core of the Aegis Legend 5 is the AS Chip 4.0, which Geekvape specifies with a 0.01-second firing speed and stable buck-boost performance for consistent output. The mod delivers up to 200W of power, with the following verified output range:
- Output power: 5–200W
- Maximum output current: 45A
- Maximum output voltage: 12V
The dual 18650 battery configuration (7.4V external) is designed to provide extended runtime between charges, and the device recharges via a Type-C port.
Vaping Modes
The Aegis Legend 5 offers multiple operating modes so you can tailor the experience to your preference and skill level. The verified parameter list specifies these modes as:
- ECO
- SMART
- NORMAL
- CUSTOM
- TC (Temperature Control)
Editorial note: Source materials list the mode names inconsistently (an alternate list cites Smart / Power / Eco / Boost / TC / Memory). The exact mode labels should be confirmed against the final product before publication.
Display and Controls
A 1.08-inch full-colour TFT screen displays your settings clearly and includes dynamic lighting. For safety, the kit features an A-Lock safety switch that helps prevent the device from firing accidentally while it’s in a pocket or bag.
Durability: IP68 Rating
The Aegis Legend 5 carries an IP68 rating, indicating resistance to water, dust, and shock. This makes it suited to outdoor use and harsher conditions where a standard mod might be more vulnerable. The device’s rated environmental limits are:
- Operating temperature: 0–45°C
- Storage temperature: -20–60°C
- Relative humidity: 45–75% RH
- Cooling: natural cooling
The Z Sub-Ohm Tank 2021
The included Z Sub-Ohm Tank 2021 uses a leak-resistant top airflow design and holds 5.5ml (a 2ml TPD-compliant glass tube is also included). It is compatible with the Geekvape Z Series coil line, which is well suited to high-VG e-liquids for dense vapour and rich flavour.
The tank’s textured airflow dial is described as Nürburgring-inspired, allowing smooth, accurate adjustment of airflow to fine-tune your draw.
Editorial note: Supported coil resistance is listed as 0.1–2Ω in the device parameters, while the feature summary cites 0.1Ω–3.0Ω for Z Series coil compatibility. Confirm the correct range before publishing.
Key Specifications at a Glance
| Specification | Detail |
|---|---|
| Output power | 5–200W |
| Max output current | 45A |
| Max output voltage | 12V |
| Supported resistance | 0.1–2Ω |
| Battery | 7.4V, dual 18650 (not included) |
| Charging port | Type-C |
| Display | 1.08-inch TFT colour screen |
| Tank capacity | 5.5ml (2ml TPD version included) |
| Water/dust/shock resistance | IP68 |
| Operating temperature | 0–45°C |
| Dimensions | 56mm (W) × 146mm (H) |
Getting Started: Practical Tips
- Batteries: You’ll need to purchase two compatible 18650 batteries separately. Match them as a pair (same brand, model, and charge level) for balanced performance.
- Coil selection: The pre-installed 0.15Ω coil is rated for 70–85W, while the spare 0.4Ω coil runs at 50–60W. Stay within each coil’s rated wattage range to preserve flavour and coil life.
- Priming coils: Before first use, allow a new coil to saturate with e-liquid to help avoid dry hits.
- Airflow: Use the textured airflow dial to adjust your draw from tighter to more open, depending on your preference.
- Safety: Engage the A-Lock switch when carrying the device to prevent accidental firing.
Conclusion
The Geekvape Aegis Legend 5 combines a 200W output ceiling, the AS Chip 4.0, and an IP68-rated build with a versatile Z Sub-Ohm Tank 2021 and multiple operating modes. Its rugged design and adjustable controls make it a flexible option for a wide range of vapers, provided you supply your own pair of 18650 batteries. With the included coils and spare parts, the kit is ready to use out of the box once batteries are added.
Frequently Asked Questions
How much power does the Aegis Legend 5 have?
Up to 200W, powered by two external 18650 batteries. Batteries are not included, so add a pair if you do not already have some.
Is the Aegis Legend 5 waterproof?
The Aegis line is built to Geekvape’s rugged standard with strong shock resistance and water and dust protection, which is why it suits people who work outdoors or travel with their kit.
What tank and coils does it use?
The kit comes with a Geekvape sub-ohm tank that takes the widely available Z Series mesh coils, known for strong flavour and long coil life.
How fast is delivery in Dubai?
Orders in Dubai usually arrive within 60 minutes. Payment is cash on delivery, and delivery across the rest of the UAE is also available.
Is the Aegis Legend 5 good for beginners?
It is a full-power mod with adjustable settings, so it suits experienced vapers best. If you are switching from cigarettes, a simple pod kit is an easier first step.
Browse more of our vape kits range for more options in Dubai and across the UAE.
